Here you will find scanned sections of a diagram prepared to show the signalling
alterations intended upon electrification of the route from Wath to Dunford Bridge.
Changes are shown in red.
The diagram was hand drawn on linen and is about 16 feet long! It was actually drawn in three
horizontal strips - adjacent strips are occasionally visible in the scans shown here.
